Small in size. Big in functionality. Despite its super-compact dimensions with a wheelbase of just 118 cm, the all-new HANS-E LT is developed from scratch to impress with its robust construction and a wide range of usability. The numbers speak for themselves: Maximum system weight: 160 kg. Maximum payload 15 kg (front) / 27 kg (rear) Remarkable: The special rear carrier construction enables upright parking to save space.
-
Frame20", lite AL-6061 tubing, Long Tail version, PowerTube battery
ForkSuntour Mobie 34 CGO NLO, 80 mm, 15x110 mm axle
Drive UnitBosch Performance Line, Gen. 3, BES3, 250 W, 36 V, max. 25 km/h
BatteryBosch PowerTube, 36 V Li Ion, 500 Wh
DisplayBosch LED Remote with Intuvia 100 display
ChargerBosch Standard Charger, 4A
ShiftersShimano Nexus, SL-C7000, 5-speed, revo-shifter
CranksetFSA CK-200, belt, 50t
BB-SetBosch
ChainGates CDX Carbon Drive Belt, Center-Track
CassetteGates CDX, 34t
Brake LeversTektro HD-M745, hydraulic disc brake
BrakesTektro HD-M745, hydraulic disc brake, 4-piston
RotorTektro TR180-35, 180 mm
GripsBGM Comfort, Ergo, double density, clamp version
HandlebarBGM Pro, high-riserbar, backsweep: 15°
H'stemSatori Fastback, with speedlifter
SeatpostSatori Trident, 450 mm
SeatSyncros Capilano Urban
HeadsetAcros, A-Headset, semi-integrated, tapered, with Visco set
Front HubShimano HB-MT400-B, centerlock, disc, 15x110 mm axle
Rear HubShimano Nexus, SG-C7000-5, freehub, centerlock, disc
SpokesSapim Leader
RimsRyde Andra 40, disc
Front TireSchwalbe Pick-Up, Super Defense, reflective stripe, 65-406Tube: Impac AV20
Rear TireSchwalbe Pick-Up, Super Defense, reflective stripe, 65-406Tube: Impac AV20
LightsFront: B&M Myc, 50 Lux, LEDRear: B&M Secuzed E, integrated in fender
RackBGM front & rear custom carrier, with Atran AVS system & easy fit window for Thule Yepp (rear), rear carrier with "vertical parking function"
FenderCurana Apollo, with stainless stays
PedalsMarwi SP-153, foldable
AccessoriesKickstand: Ursus Jumbo Evo, 2-legged
Approx weight in KG32
Colorshiny glazy blue
Frame sizeone size
Max. System Weight160,0 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
