More autonomy, more connectivity and the latest Bosch technology featured in an accessible package. From off road commuting to your local trails, the Aspect is all about versatility and fun.
-
Frame
Alloy XS-XL=29", 6061 Alloy custom butted tubing
Side extraction battery
UDH Interface, 12x148mm with 52mm Chainline -
Travel
120mm -
Fork
SR Suntour XCM34 RL Coil, Tapered 120mm Travel, 15x110 bolt Axle, Remote Lock Out -
Remote System
SR Suntour Remote
-
Drive Unit
Bosch Performance Line CX (BDU384Y)
EU: 25kmh -
Battery
PowerTube 600Wh -
Display
Bosch System Controller
Intuvia 100
Mini Remote -
Charger
2A Charger -
Rear Derailleur
SRAM NX Eagle, 12 Speed -
Shifters
SRAM SX Eagle Single Click Trigger -
Crankset
FSA CK-220
165mm -
Chainring
SRAM CR T-Type 36T DM w/Chain Guard -
Chain
SRAM SX Eagle -
Cassette
SRAM PG1210, 11-50 -
Brakes
Shimano BR-MT420 Disc Brakes -
Rotor
Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 180mm -
Handlebar
Syncros 3.0 720mm, 31.8mm, 9°, 12mm rise
Syncros Comfort lock-on grips -
H'stem
Syncros AM2.0, 6061 Alloy
31.8mm, 0° -
Seatpost
Syncros M3.0, 31.6mm
350mm -
Seat
Syncros Tofino E 2.0 -
Headset
Acros, 1.5"- 1.5"
semi integ. OD 50/61mm, ID 44/55mm -
Hub (Front)
Formula CL-811, 15x110mm -
Hub (Rear)
Formula CL-148S, 148x12mm -
Spokes
Stainless Black -
Rims
Cross X19, 32H, 30mm, Pin Joint -
Front Tire
Kenda Booster 29x2.6", 30TPI -
Rear Tire
Kenda Booster 29x2.6", 30TPI -
Lights
Bosch Light Cable pre-installed F&R -
Approx weight in KG
25.8 -
Approx weight in LBS
56.88 -
Max. System Weight
130kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Please note that bike specifications are subject to change without prior notice.
