Adventures across all terrains. The HAIBIKE ALLTRACK 6 is a reliable hardtail eMTB for sporty rides – an off-road champion that cuts a fine figure on every surface with its stylish, fully integrated design. The bold new colours shout speed, and the equipment is performance-focused too. The all-new Bosch Performance Line PX motor and 800Wh battery ensure you never run out of power. Durable components like the Shimano drivetrain and disc brakes, plus the SR Suntour suspension fork with 120mm travel, promise a safe and comfortable ride – and plenty of adventure. Good to know: the ALLTRACK 6 comes with 27.5" wheels in frame size S and 29" wheels in sizes M to XL.
Alloy Frame
Suntour XCM34 120mm Fork
Bosch Performance Line PX
800Wh Powertube Battery
Shimano CUES 10 Speed Gearing
Bike Geometry
-
Bottom bracket drop [mm]:
- · 60 mm
- · 65 mm
-
Chain stay length [mm]:
- · 465 mm
- · 475 mm
- Fork total length [mm]: 44 mm
-
Head tube angle:
- · 68 degrees
- · 67 degrees
-
Head tube length [mm]:
- · 140 mm
- · 160 mm
- · 150 mm
-
Reach [mm]:
- · 422 mm
- · 472 mm
- · 452 mm
- · 432 mm
-
Stack [mm]:
- · 656 mm
- · 692 mm
- · 683 mm
- · 674 mm
-
Stand over height [mm]:
- · 760 mm
- · 780 mm
- Seat tube angle: 74 degrees
-
Seat tube length [mm]:
- · 400 mm
- · 550 mm
- · 500 mm
- · 450 mm
-
Top tube length [mm]:
- · 610 mm
- · 670 mm
- · 648 mm
- · 625 mm
-
Wheelbase [mm]:
- · 1171 mm
- · 1264 mm
- · 1240 mm
- · 1216 mm
Brake system
- Brake Front Description: Tektro, Hydraulic Disc brake, HD-M280, 2 pistons, 180 mm
- Brake Front Mount: Post Mount
- Brake Rear Description: Tektro, Hydraulic Disc brake, HD-M280, 2 pistons, 180 mm
- Brake Rear Mount: Post Mount
- Brake Lever Description: Tektro, HD-M280-BL
- Brake Rotor Description: Tektro, TR180-53 180 mm, 6 bolt Disc
Drivetrain
- Cassette Description: Shimano, CUES CS-LG300-10, HG
- Cassette Teeth: 11-48T
- Chain Description: KMC, Chain, eGlide with EPT Coating 9-11s
- Crank Arm length: 170
- Crankset Description: XLC, CR-E18 Crankset + CR-E15 Chainring Bosch BDU38
- Crankset Teeth: 38T
- Crankset Type: single
- Derailleur Hanger Description: XLC, UDH
- Derailleur Rear Description: Shimano, CUES RD-U6000 10/11s, Shadow+
- Gear Description: Shimano, Derailleur, CUES
- Number Of Gears: 10
- Pedal Description: XLC, Flat Pedal PD-M29 w/ Reflector + integrated Pins
- Pedal Inclusive: Yes
- Shifter Right Description: Shimano, Triggershift, CUES SL-U6000-10R, Rapidfire+
E-bike components
- Battery Description: Bosch, InTube 800Wh
- Battery Capacity: 800 Wh
- Battery Location: Powertube
- Battery Removeable: Yes
- Charger Description: Bosch, Charger 2A 220-240V
- Display Description: Bosch, Purion 200, Purion 200
- Motor Description: Bosch, Performance Line PX
- Motor Torque [nm]: 85 Nm
- Motor Location: Center
Frame and more
-
Framesize:
- · 40 cm
- · 55 cm
- · 50 cm
- · 45 cm
-
Framesize Convection:
- · S
- · XL
- · L
- · M
- Max loadable weight (KG): 150 kg
- Front Fork Description: Suntour, XCM34-Boost NLO 15AH4-110 120 mm
- Front Fork Type: Suspension
- Frame Description: High, Aluminium, Uni
- Suspension Type: Hardtail
- Travel Front: 120 mm
Handlebar and Saddle
- Handgrip Description: XLC, MTB Grip Set VLG-1751D2
- Handlebar Description: XLC, Riser Bar, HB-M32, Dia. 31.8 mm, Rise: 20 mm, backsweep 9°
- Handlebar Diameter: 31.8 mm
- Handlebar Material: Aluminium
- Handlebar Rise: 20
- Handlebar Width: 780 mm
- Headset Description: Feimin, Semi-integrated, FP-H856U ZS44 + ACROS BlockLock ZS56
- Saddle Description: XLC, SA-S10 143 mm Sport
- Seatpost Description: XLC, Non Suspension, SP-R30, Dia. 34.9 mm, L: 300 mm, 300 mm
- Seatpost Material: Aluminium
- Stem Description: XLC, ST-M34, Dia. 31.8 mm, L: 50 mm, +/-7°, A-Head
- Stem Length: 50 mm
Lighting
- Brake Light: No
Wheels and wheel components
- Hub Front Description: XLC, HF-M15 Boost 15x110 mm, 32H, 6 bolt Disc
- Hub Rear Description: XLC, HR-M15 Boost 12x148 mm, 32H, 6 bolt Disc, HG
- Rim Description: XLC, WR-M37 Disc 30/584 32H 6,5 mm Valve
- Rim Rear Description: XLC, WR-M37 Disc 30/584 32H 6,5 mm Valve
- Spoke Description: Sapim, Leader Dia. 2.0 mm
- Tyre Description: XLC, VT-M30 Cirrus, 66-584
- Tyre Rear Description: XLC, VT-M30 Cirrus
- Wheelsize Description: 27.5, 27.5
