The Scale Gravel was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, the Scale Gravel is lightweight with agile handling and features multiple mounting options.
Please note that bike specifications are subject to change without prior notice.
Frame and Suspension
- Frame: Scale HMF Carbon, adjustable head angle, Syncros Cable Integration System, advanced shock & standing damping system, BB92, UDH interface, 12x148mm with 55mm chainline
- Fork: Scale Rigid HMF, postmount disc standard, tapered carbon steerer
Drivetrain
- Rear Derailleur: SRAM S1000 Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System
- Shifters: SRAM AXS Pod Controller
- Crankset: SRAM Eagle 70 Transmission, DUB, 55mm CL, 34T
- Chainguide: SCOTT custom
- BB-Set: SRAM DUB PF 92 MTB Wide, shell 41x92mm
- Chain: SRAM Eagle 70 Transmission
- Cassette: SRAM Eagle XS-1270 Transmission, 10-52T
Brake System
- Brakes: SRAM DB6 4-Piston
- Front Disc Rotor: SRAM Centerline CL, 180mm
- Rear Disc Rotor: SRAM Centerline CL, 160mm
Cockpit and Seating
- Grips: Syncros Performance XC Lock-On
- Handlebar: Syncros Alloy 6061, T shape Flat, 9°, 740mm
- H'stem: Syncros Alloy 6061, oversized 31.8mm, 1 1/8", 6° angle
- Seatpost: Syncros alloy, 10mm offset, 31.6x400mm
- Seat: Syncros Celista Cut Out
- Headset: Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Wheels and Tires
- Front Hub: Formula CL-811, 15x110mm
- Rear Hub: Formula CL-3248, 12x148mm
- Spokes: Stainless Black
- Front Rim: Alex Rims X-30S 32H, Sleeve Joint, Tubeless ready
- Rear Rim: Alex Rims X-30S 32H, Sleeve Joint, Tubeless ready
- Front Tire: Maxxis Aspen 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
- Rear Tire: Maxxis Aspen 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
Extras and Accessories
- Accessories: Spirgrips Inner Bar ends, SRAM AXS powerpack
Weight
- Approx weight in KG: 11.4 Tubless
- Approx weight in LBS: 25.13 Tubless
- Max. System Weight: 130kg
- Note: The overall weight includes the bike, the rider, the equipment and possible additional luggage.
