The Scale Gravel was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, the Scale Gravel is lightweight with agile handling and features multiple mounting options.
Please note that bike specifications are subject to change without prior notice.
What’s New
- What's new: Shimano Deore
Frame and Suspension
- Frame: Scale Alloy 6061 Custom Butted Tubing, Tapered Headtube, BB92, UDH interface, Boost 12x148mm with 55mm chainline
- Fork: Scale Rigid HMF, postmount disc standard, tapered carbon steerer
Drivetrain
- Rear Derailleur: Shimano Deore RD-M7200 12-speed
- Shifters: Shimano Deore SL-M6200
- Crankset: Shimano FC-MT520, 34T
- BB-Set: Shimano BB-MT500 PF
- Chain: Shimano CN-M6100
- Cassette: Shimano Deore CS-M6200, 10-51T
Brake System
- Brakes: Shimano BR-MT401 2-Piston
- Front Disc Rotor: Shimano SM-RT10 CL, 180mm
- Rear Disc Rotor: Shimano SM-RT10 CL, 160mm
Cockpit and Seating
- Grips: Syncros Performance XC
- Handlebar: Syncros Alloy 6061, T shape Flat, 9°, 740mm
- H'stem: Syncros Alloy 6061, oversized 31.8mm, 1 1/8", 6° angle
- Seatpost: Syncros alloy, 10mm offset, 31.6x400mm
- Seat: Syncros Celista Cut Out
- Headset: Cable Routing Headset ZS56/28.6 – ZS56/40
Wheels and Tires
- Front Hub: Formula CL-811, 15x110mm
- Rear Hub: Formula FCL-548M, 148x12mm, Micro Spline
- Spokes: Stainless Black
- Front Rim: Alex Rims X-30S 32H, Sleeve Joint, Tubeless ready
- Rear Rim: Alex Rims X-30S 32H, Sleeve Joint, Tubeless ready
- Front Tire: Maxxis Aspen 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
- Rear Tire: Maxxis Aspen 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
Extras and Accessories
- Pedals: Feimin FP-873ZU
- Extras: Spirgrips Inner Bar ends
Weight
- Approx weight in KG: 11.7 without pedals
- Approx weight in LBS: 25.79 without pedals
- Max. System Weight: 130kg
- Note: The overall weight includes the bike, the rider, the equipment and possible additional luggage.
