The SCOTT SUB Sport 40 Wave E-Bike turns everyday riding into a smoothly balanced, supported, and truly enjoyable part of the day. Plus, its low step-through frame makes hopping on and off effortless. Power comes from Bosch’s Active Line Plus motor paired with a removable 540Wh battery, delivering a naturally smooth acceleration and a range that comfortably covers school runs, commuter trips, and longer weekend outings. Multiple assist modes let you dial in exactly the amount of boost you need—whether you need a strong surge to tackle a hill with a loaded bike or just a gentle sip of power to glide through traffic.
The stem is fully adjustable, so you can transition from a relaxed, ergonomic posture for a leisurely ride to a sportier, more responsive position when you need to move quickly. An integrated SP connection securely holds your phone, keeping navigation in clear view and your hands free for a safer, more attentive ride.
The rear rack supports up to 30kg and is compatible with Racktime SNAPIT 2.0 and KID'n’CARRY systems, making cargo simple to attach. And the front light is positioned on the fork, freeing up space for a front basket so you can keep essentials within arm’s reach.
A front-suspension fork smooths out potholes and uneven sidewalks, while Shimano’s reliable 9-speed drivetrain provides precise gearing for any terrain you encounter, helping you stay on schedule without missing a beat.
Please note that bike specifications are subject to change without prior notice.
What’s New
- What's new: SP connect, Kid 'n Carry Ready
Frame and Suspension
- Frame: Alloy S-XL=29", 6061 Alloy custom butted tubing, Top extraction battery, UDH Interface, 141mm QR with 52mm Chainline
- Travel: 100mm
- Fork: SR Suntour NVX 32 5TA COIL LO
Motor and Battery
- Drive Unit: Bosch Active Line Plus (BDU344Y)
- Battery: Bosch PowerTube 540Wh
- Display: Bosch Purion 200
- Charger: Bosch 2A Charger 230V
Drivetrain
- Rear Derailleur: Shimano Cues RD-U4000 9-Speed
- Shifters: Shimano Cues SL-U4000 With Display
- Crankset: FSA CK 220 170mm
- Chainguide: Chaincase cover
- Chainring: FSA 38T w/o Chain Guard
- Chain: Shimano CN-LG500
- Cassette: Shimano Cues CS-LG300, 9-Speed 11-46T
Brake System
- Brakes: Shimano BR-MT200 2-Piston
- Front Disc Rotor: Shimano SM-RT30 CL, 180mm
- Rear Disc Rotor: Shimano SM-RT30 CL, 160mm
Cockpit and Seating
- Grips: Urban Comfort
- Handlebar: Syncros UC3.0 680mm, Rise 26mm, Backsweep 30°
- H'stem: JD, Adjustable, 31.8*90 mm −10°~+60°, SP Connect
- Seatpost: Syncros M3.0, 31.6mm, 350mm
- Seat: Selle Royal Explora Moderate Wide 195mm
- Headset: Feimin, 28.8-56-62(39.8/30), H887 Bearing Cup
Wheels and Tires
- Front Hub: Shimano HBQC400B58LL, 5x100mm
- Rear Hub: Shimano FH-QC400-HM QR
- Spokes: Stainless Black 13G
- Front Rim: X18 Disc
- Rear Rim: X18 Disc
- Front Tire: Schwalbe Big Apple Performance, 55-622
- Rear Tire: Schwalbe Big Apple Performance, 55-622
Lights and Equipment
- Front Light: Lezyne Mini Lite STVZO E350
- Rear Light: Lezyne Superbright STVZO
- Rack: Racktime carrier SNAPIT 2.0 30Kg KID'n'CARRY Ready
- Fender: Metasol 65
- Pedals: Marwi SP-827
Extras and Accessories
- Extras: Ursus U-Mount Kickstand
Weight
- Approx weight in KG: 30.25
- Approx weight in LBS: 66.69
- Max. System Weight: 160kg
- Note: The overall weight includes the bike, the rider, the equipment and possible additional luggage.
